Deshengxin F6 Medium-Efficiency Bag Filter Product Introduction

Deshengxin proudly presents the F6 Medium-Efficiency Bag Filter, a reliable and efficient filtration solution designed for preliminary to intermediate filtration in ventilation systems. This filter is specifically engineered to capture coarse dust and foreign particles larger than 1μm, ensuring cleaner air for your environment.

Product Structure: The F6 Bag Filter features a sturdy frame available in aluminum alloy, galvanized steel, or ABS plastic, accommodating various installation needs. The filter media is composed of high-quality polyester fiber filter cotton, utilizing a progressively denser grading technology to enhance filtration performance and dust holding capacity. The filter bags are seamlessly sealed using five-thread stitching or high-frequency thermal welding, and are securely fixed to the inner frame with perforated riveting or metal strip clamping.

Efficiency Rating: F6

Product Features:

1. High-Quality Polyester Fiber Media: Crafted with progressively denser grading technology, it offers excellent filtration performance and high dust holding capacity.

2. Standard V-Shaped Bag Structure: Designed to conform to airflow patterns, enhancing stability and maximizing the effective use of the filtration media for better filtration results.

3. Rigid Connection Structure: Ensures tight sealing between the filter bag and support frame, guaranteeing operational reliability and eliminating secondary dust generation.

4. Silicon-Free Design: Suitable for use in paint spraying workshops.

5. Low Resistance and Large Filtration Area: Offers high humidity resistance up to 100%, is washable and reusable, providing cost-effective filtration.

6. Customizable Frame Thickness: Available in thicknesses of 21mm, 25mm, 46mm, and customizable based on requirements.

7. Operational Limits: Suitable for use at temperatures up to 80°C and humidity levels of 100% RH.

8.


Applications:

1. Pre-filtration in HVAC Systems: Protects the internal components of ventilation systems from dust accumulation and contamination.

2. Centralized Ventilation and Air Conditioning Systems in Cleanrooms: Extends the lifespan of subsequent filters by capturing coarse dust and particles.

3. Ventilation Systems in Industrial Plants: Meets general air cleanliness requirements for ordinary industrial environments.

4. Coarse Dust Filtration in Commercial Building HVAC Systems: Provides initial filtration for air conditioning systems in general buildings.

Choose the Deshengxin F6 Medium-Efficiency Bag Filter for reliable and efficient intermediate filtration, maintaining a clean and healthy air environment in your HVAC systems, cleanrooms, and industrial ventilation applications.
